LOX/LAR/LIN/LCo2 Air Ambient Vaporizer for Gas Station
Ambient Vaporizer Specification:
1.Liquid Fluid Rate:50-1500Nm3/H
2.Working Pressure:4BAR-350BAR
3.Medium:LAR/LIN/LOX/LPG/LNG
4.Ambient Vaporizer Material:Aluminum
5.Installation Type:Fixed by Anchor Bolt
6.Inlet/Outlet Valve:DN20
Ambient Vaporizer Introduction:
A vaporizer which derives energy for vaporizing and heating liquid gas from storage conditions to send out conditions from naturally occurring sources such as the atmosphere, sea water, or geothermal waters.
Contact:
Ambient Vaporizer Specification:
1.Liquid Fluid Rate:50-1500Nm3/H
2.Working Pressure:4BAR-350BAR
3.Medium:LAR/LIN/LOX/LPG/LNG
4.Ambient Vaporizer Material:Aluminum
5.Installation Type:Fixed by Anchor Bolt
6.Inlet/Outlet Valve:DN20
TYPE | Pressure(BAR) | Vaporizer QTY (Nm3/h) | (°C) | SIZE L×W×H(mm) | NOTE |
| CYY-50/4-350 | 4-350 | 50 | -10~40 | 693×439×3165 | Φ160 |
| CYY-100/4-350 | 100 | 947×693×3165 | |||
| CYY-150/4-350 | 150 | 947×947×3165 | |||
| CYY-200/4-350 | 200 | 1455×947×3165 | |||
| CYY-250/4-350 | 250 | 1709×947×3165 | |||
| CYY-300/4-350 | 300 | 1963×947×3165 | |||
| CYY-350/4-350 | 350 | 1963×1201×3165 | |||
| CYY-400/4-350 | 400 | 1963×1455×3165 | |||
| CYY-450/4-350 | 450 | 2471×1201×3165 | |||
| CYY-500/4-350 | 500 | 1963×1709×3165 | |||
| CYY-600/4-350 | 600 | 1963×1963×3165 | |||
| CYY-700/4-350 | 700 | 2217×1963×3165 | |||
| CYY-800/4-350 | 800 | 2471×1963×3165 | |||
| CYY-900/4-350 | 900 | 2471×2122×3165 | |||
| CYY-1000/4-350 | 1000 | 2471×2471×3165 | |||
| CYY-1200/4-350 | 1200 | 2471×2122×4165 | |||
| CYY-1500/4-350 | 1500 | 2471×2122×4765 |
Ambient Vaporizer Introduction:
A vaporizer which derives energy for vaporizing and heating liquid gas from storage conditions to send out conditions from naturally occurring sources such as the atmosphere, sea water, or geothermal waters.
